Need a Composite?
COSMO® SILENT Panels
Sound-insulating composite panels
Noise is a problem of our modern time. Our environment becomes increasingly noisier. Therefore, it is an important task, to reduce noise pollution effectively to a minimum. We took up this challenge and developed a series of sandwich elements that have special noise control characteristics in addition to outstanding heat insulation. These elements can be used, for instance, in window sills, doors, shutter housings, machines, or equipment housings or as sound-absorbing hoods.
We are offering sandwich elements of several sound transmission classes (I to V), from which a huge number has been tested by the ift (Institut für Fenstertechnik) referring their noise insulation characteristics.
COSMO® Silent (dB 38) – ALU
ALU on both sides, XPS core, ALU insert
Composite panels with special sound insulation (dB38), consisting of a pure aluminium cover sheet AlMg1 with a thickness of 1,0mm and a core of extruded polystyrene foam (XPS).
Product details
COSMO® Silent (dB 46/50) – ALU
ALU on both sides, core of mineral wool, heavy-film insert
Composite panels with special sound insulation (dB46 – dB50), consisting of a pure aluminium cover sheet with a thickness of 1,5 – 2,0mm and a core of mineral fibre insulation (MIN).
Product details
COSMO® Silent (dB 37) – PVC
PVC on both sides, PUR core, heavy film insert
Composite panels with special sound insulation (dB37), consisting of PVC compact panels with a thickness of 2,0mm and a core of polyurethane foam (PUR).
Product details
COSMO® Silent (dB 34/36/38) – PVC
PVC on both sides, XPS core, heavy film insert
Composite panels with special sound insulation (dB34 – dB38), consisting of PVC compact panels with a thickness of 1,5 – 2,0mm and a core of extruded polystyrene foam (XPS).
Product details
COSMO® Silent (dB 42) – PVC
PVC on both sides, core of mineral wool
Composite panels with special sound insulation (dB42), consisting of PVC compact panel with a thickness of 2,0mm and sound insulating filler and a core of mineral fibre insulation (MIN).
Product details
COSMO® Silent (dB 45/47) – HPL
HPL on both sides, core of mineral wool
Composite panels with special sound insulation (dB46, dB47), consisting of a high pressure laminate (HPL) with a thickness of 2,0mm and a core of mineral fibre insulation (MIN).
Product details
COSMO® Silent (dB) – HPL/HD
bilateral HPL/HD, XPS-core, Heavy foil insert.
Sandwich panels with special sound-insulating properties consisting of decored high-pressure laminated laminated sheets (HPL) with a thickness of 2.0mm and an inner core made of extruded polystyrene rigid foam (XPS).
Product details
